Abstract base class of all PCL geometric image transformations. More...

#include <GeometricTransformation.h>

Inheritance diagram for pcl::GeometricTransformation:

Public Member Functions
	GeometricTransformation ()=default

	GeometricTransformation (const GeometricTransformation &)=default

	GeometricTransformation (GeometricTransformation &&)=default

	~GeometricTransformation () override

virtual void	GetNewSizes (int &width, int &height) const =0

GeometricTransformation &	operator= (const GeometricTransformation &)=default

GeometricTransformation &	operator= (GeometricTransformation &&)=default

Public Member Functions inherited from pcl::ImageTransformation
	ImageTransformation ()=default

	ImageTransformation (const ImageTransformation &)=default

virtual	~ImageTransformation ()

template<class P >
GenericImage< P > &	operator>> (GenericImage< P > &image) const

ImageVariant &	operator>> (ImageVariant &image) const

Static Public Member Functions
template<class P >
static void	ApplyGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplyInverseGammaExponentCorrection (typename P::sample *samples, size_type length, double gamma, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplyInverseSRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

template<class P >
static void	ApplySRGBGammaCorrection (typename P::sample *samples, size_type length, AbstractImage::ThreadData &threadData, int maxProcessors=PCL_MAX_PROCESSORS)

Additional Inherited Members
Protected Member Functions inherited from pcl::ImageTransformation
virtual void	Apply (pcl::ComplexImage &image) const

virtual void	Apply (pcl::DComplexImage &image) const

virtual void	Apply (pcl::DImage &image) const

virtual void	Apply (pcl::Image &image) const

virtual void	Apply (pcl::UInt16Image &image) const

virtual void	Apply (pcl::UInt32Image &image) const

virtual void	Apply (pcl::UInt8Image &image) const

Detailed Description

GeometricTransformation represents a geometrical transformation that can be applied to any image type defined in PCL.

See also: InterpolatingGeometricTransformation, ImageTransformation

Definition at line 77 of file GeometricTransformation.h.

Constructor & Destructor Documentation

◆ GeometricTransformation() [1/3]

pcl::GeometricTransformation::GeometricTransformation ( )

default

Constructs a GeometricTransformation object.

◆ GeometricTransformation() [2/3]

pcl::GeometricTransformation::GeometricTransformation ( const GeometricTransformation & )

default

Copy constructor.

◆ GeometricTransformation() [3/3]

pcl::GeometricTransformation::GeometricTransformation ( GeometricTransformation && )

default

Move constructor

◆ ~GeometricTransformation()

pcl::GeometricTransformation::~GeometricTransformation ( )

inlineoverride

Destroys a GeometricTransformation object.

Definition at line 109 of file GeometricTransformation.h.

Member Function Documentation

◆ ApplyGammaExponentCorrection()

template<class P >

static void pcl::GeometricTransformation::ApplyGammaExponentCorrection	(	typename P::sample *	samples,
		size_type	length,
		double	gamma,
		AbstractImage::ThreadData &	threadData,
		int	maxProcessors = `PCL_MAX_PROCESSORS`
	)

inlinestatic

Applies a gamma correction function to a block of pixel sample values.

Parameters

[in,out]	samples	Pointer to the start of a contiguous block of pixel sample values. On input, these values must be expressed in a nonlinear color space with the specified gamma exponent. On output, these values will be expressed in a linear color space.
	length	Number of pixel sample values to process.
	gamma	The gamma exponent of the nonlinear color space. A value gamma > 0 must be specified.
	threadData	Reference to an AbstractImage::ThreadData object for thread control and monitoring.
	maxProcessors	Maximum number of parallel threads to use. The default value does not impose a practical limit.

Definition at line 232 of file GeometricTransformation.h.

◆ ApplyInverseGammaExponentCorrection()

template<class P >

static void pcl::GeometricTransformation::ApplyInverseGammaExponentCorrection	(	typename P::sample *	samples,
		size_type	length,
		double	gamma,
		AbstractImage::ThreadData &	threadData,
		int	maxProcessors = `PCL_MAX_PROCESSORS`
	)

inlinestatic

Applies an inverse gamma correction function to a block of pixel sample values.

Parameters

[in,out]	samples	Pointer to the start of a contiguous block of pixel sample values. On input, these values must be expressed in a linear color space. On output, these values will be expressed in a nonlinear color space with the specified gamma exponent.
	length	Number of pixel sample values to process.
	gamma	The gamma exponent of the nonlinear color space. A value gamma > 0 must be specified.
	threadData	Reference to an AbstractImage::ThreadData object for thread control and monitoring.
	maxProcessors	Maximum number of parallel threads to use. The default value does not impose a practical limit.

Definition at line 271 of file GeometricTransformation.h.

◆ ApplyInverseSRGBGammaCorrection()

template<class P >

static void pcl::GeometricTransformation::ApplyInverseSRGBGammaCorrection	(	typename P::sample *	samples,
		size_type	length,
		AbstractImage::ThreadData &	threadData,
		int	maxProcessors = `PCL_MAX_PROCESSORS`
	)

inlinestatic

Applies an inverse sRGB gamma correction function to a block of pixel sample values.

Parameters

[in,out]	samples	Pointer to the start of a contiguous block of pixel sample values. On input, these values must be expressed in a linear color space. On output, these values will be expressed in the sRGB color space.
	length	Number of pixel sample values to process.
	threadData	Reference to an AbstractImage::ThreadData object for thread control and monitoring.
	maxProcessors	Maximum number of parallel threads to use. The default value does not impose a practical limit.

Definition at line 339 of file GeometricTransformation.h.

◆ ApplySRGBGammaCorrection()

template<class P >

static void pcl::GeometricTransformation::ApplySRGBGammaCorrection	(	typename P::sample *	samples,
		size_type	length,
		AbstractImage::ThreadData &	threadData,
		int	maxProcessors = `PCL_MAX_PROCESSORS`
	)

inlinestatic

Applies an sRGB gamma correction function to a block of pixel sample values.

Parameters

[in,out]	samples	Pointer to the start of a contiguous block of pixel sample values. On input, these values must be expressed in the sRGB color space. On output, these values will be expressed in a linear color space.
	length	Number of pixel sample values to process.
	threadData	Reference to an AbstractImage::ThreadData object for thread control and monitoring.
	maxProcessors	Maximum number of parallel threads to use. The default value does not impose a practical limit.

Definition at line 306 of file GeometricTransformation.h.

◆ GetNewSizes()

virtual void pcl::GeometricTransformation::GetNewSizes	(	int &	width,
		int &	height
	)		const

pure virtual

Predicts transformed image dimensions.

Parameters

[in,out]	width	Reference to a variable whose value is a horizontal dimension in pixels (width). On output, it will receive the predicted horizontal dimension after the transformation.
[in,out]	height	Reference to a variable whose value is a vertical dimension in pixels (height). On output, it will receive the predicted vertical dimension after the transformation.

Note: This is a pure virtual member function that must be reimplemented in every derived class.

Implemented in pcl::Translation, pcl::Rotation, pcl::Resample, pcl::IntegerResample, pcl::Crop, pcl::AstrometricReprojection, pcl::PolarTransformBase, pcl::VerticalMirror, pcl::HorizontalMirror, pcl::Rotate90CCW, pcl::Rotate90CW, and pcl::Rotate180.

◆ operator=() [1/2]

GeometricTransformation& pcl::GeometricTransformation::operator= ( const GeometricTransformation & )

default

Copy assignment operator. Returns a reference to this object.

Referenced by pcl::InterpolatingGeometricTransformation::operator=().

◆ operator=() [2/2]

GeometricTransformation& pcl::GeometricTransformation::operator= ( GeometricTransformation && )

default

Move assignment operator. Returns a reference to this object.

The documentation for this class was generated from the following file:

GeometricTransformation.h
